Laguna Tools Classic Double Drum Sander 25x2 - SUPMX-913002
Laguna Tools Classic Double Drum Sander 25x2 - SUPMX-913002
Laguna Tools Classic Double Drum Sander 25x2 - SUPMX-913002
Sand two grits in a single pass with a 25×2 Double Drum Sander. Featuring INTELLISAND Technology and a 5 HP motor, you can significantly reduce the amount of time you spend sanding.
Need a larger machine? Check out our 37×2 Drum Sander.
Features
-
INTELLISAND™ Technology: Automatically adjusts conveyor speed based on load
- Prevents gouging, damaging or burning stock
- Provides consistent finish even with varying grain pattern and density
- Greatly increases abrasive planing and dimensioning speed
- Flatness Guarantee: Precision-flattened steel conveyor bed reinforced with four steel cross sections for no “flex” in conveyor, guaranteeing flatness to less than .010″ across the width of the sander
- Abrasive conveyor belt offers the best grip for raw wood, giving you the ability to accommodate stock that is much shorter or thinner
- Patented Abrasive Attachment System effectively tensions the abrasive wraps, preventing loose abrasive and overlap
- Easiest access to abrasive fastening system of any drum sander! Extra wide space to access fasteners to eliminate need for special tools
- Self-cooling drum prevents overheating and extends abrasive life
- Tension rollers are adjustable in height and hold down pressure, eliminating snipe
-
Excellent dust extraction as dust cover is formed to shape of drum
- Metal, not plastic, is formed to maximize air flow and dust extraction
- Heavy-duty cast iron construction for strength, rigidity and reduced vibration
- Mobile base allows for stand and machine to be to moved easily
Specifications
The 25×2 Double Drum Sander features INTELLISAND Technology that auto-regulates the conveyor based on load, preventing burning, gouging, and damaging stock. The machine comes standard on an open-column base, and features a 5 HP motor.
Sanding Capacity
- Maximum Width (in): 25″
- Minimum Length (in): 3-½″
- Maximum Thickness (in): 6″
- Minimum Thickness (in): 1/32″
- Dimensions (H x W x D): 43″ x 46″ x 31″
- Drum (Extruded Aluminum): 5″ x 25″
- Drum Speed: 1740 RPM
- Dust Hood (Steel Hood, Hinged At Back): (2) 4″ Vacuum Ports, Min CFM: 1000 Recommended
- Ball Bearing (1″): 4 sealed and permanently lubricated
- Conveyor Motor: 100 in. -lb. torque, direct drive D.C. motor, ranged variable, 0-15 FPM
- Drive Motor (TEFC): 5 HP, 1 Phase
- Power Requirements: 208-230V, 60Hz; 1 Phase, 30 Amp Service; 3 Phase 20 Amp Service
- Shipping Weight: 475 lbs
- Shipping Dimensions (L x W x H): 50″ x 44-½″ x 44
Video
What Our Experts Think
-
High-Throughput Performance: The 25″ wide double-drum setup lets you sand rough stock and finish in one pass, saving time and improving efficiency.
-
Smart Conveyor Control: The IntelliSand® system automatically adjusts feed rate to prevent gouging, burning, or uneven sanding.
-
Precision Flat Results: Reinforced steel conveyor bed ensures exceptional flatness with minimal variation across the surface.
-
Heavy-Duty Build & Dust Management: Cast-iron frame and dual 4″ dust ports keep vibration low and the workspace clean.
-
Perfect for Mid-Size Shops: Compact yet powerful, it handles material up to 25″ wide and 6″ thick — ideal for professional workshops.
Q&A
Q: What is the maximum sanding width?
A: It can sand up to 25″ wide material.
Q: What’s the maximum thickness capacity?
A: Handles stock up to 6″ thick efficiently.
Q: What motor does it use?
A: Powered by a robust 5 HP motor designed for 220 V single-phase operation.
Q: How fast do the drums spin?
A: Each drum runs at approximately 1,740 RPM for smooth and even results.
Maintenance Tips
-
Clean Regularly: Remove dust and resin buildup from conveyor and drums after each use.
-
Adjust Tension Rollers: Keep roller pressure even to prevent snipe and ensure smooth feeding.
-
Lubricate Bearings: Check and oil bearings periodically to maintain long-term reliability.
-
Inspect Belts & Conveyor: Ensure correct alignment and tension for consistent feed rate.
-
Keep Dust Ports Clear: Maintain open airflow through both 4″ ports to prevent clogging and ensure optimal sanding performance.
